Boiler Tubes

Product Specification
Tube OD:	6mm to 273mm	0.236" to 10" (NPS)
Tube WT:	1mm to 30mm	0.04" to 1.18"
Tube Length:	30000mm max	98ft max

Material

Tube Material:

Carbon Steel: most common grades are SA192, SA106Gr.B, SA210A1, SA210C, 20G, P235GH, P265GH, STB410
Stainless Steel: most common grades are TP304, TP316, TP321, TP347, 2205, 2507
Alloy Steel: most common grades are T5, T9, T11, T12, T22, T91, P5, P9, P11, P12, P22, P91, 16Mo3, 09CrCuSb, 12Cr1MoVG, 15CrMo
Copper: most common grades are UNS12200, 14200, 70600, CuNi70/30, CuNi90/10
Nickel: most common grades are Inconel 625, Incoloy 825, Monel 400, Hastelloy C276
Titanium: most common grade is SB338Gr.2

* This table is used as a general guide to our capabilities, please contact us for any other customized cases.

Standard & Specification
ASTM A106 Steel Pipe for High-Temperature Service
ASTM A192 Steel Boiler Tubes for High Pressure Service
ASTM A210 Carbon Steel Boiler and Superheater Tubes
ASTM A312 Seamless and Welded Stainless Steel Pipes
ASTM A335 Alloy Steel Pipe for High Temperature Service
ASTM A789 /790 Seamless and Welded Stainless Steel Pipe
ASTM B163 /B165 /B167 /B407 /B423 /B444 /B622 /B677 /B690 /B704 /B829 Nickel Alloy Tubes & Pipes
ASTM B338 Titanium and Titanium Alloy Tubes
DIN 17175 Seamless Tubes of Heat-resistant Steels
DIN 17456 /17458 Seamless Circular Stainless Steel Tubes
EN 10216-2 Seamless Steel Tubes for Pressure Purposes
EN 10216-5 Stainless Steel Tubes for Pressure Purposes
TU 14-3-190-2004 /14-3-460-2003 Steel Tubes for Boilers
TU 14-3R-55-2001 Seamless Steel Pipes for Steam Boilers
GOST 9940-81 /9941-81 Seamless Stainless Steel Pipes
JIS G3461 Carbon Steel Boiler Tubes
JIS G3462 Alloy Steel Boiler Tubes
BS 3059-2 Steel Boiler and Superheater Tubes
GB/T 150.2 Steel Tubes Used for Pressure Vessels
GB/T 3087 Steel Tubes for Low and Medium Pressure Boiler
GB/T 5310 Steel Tubes and Pipes for High Pressure Boiler
GB/T 13296 Seamless Stainless Steel Tubes for Boiler
